PROPERTY | TEST METHOD | NOTES | METRIC | UNITS | IMPERIAL | UNITS |
Colour | Green | Green | ||||
Density | ISO 1183:1997 | Test Method A | g/cm³ | 1.138 | lb/inchE3 | 0.041 |
Moisture Absorption (Equilibrium) | ISO 62:1999 (modified) | 50% RH, 23°C | % | 2 | % | 2 |
Water Absorption @24 hrs |
ISO 62:1999 (modified) | Immersion @ 23°C | % | 0.2 | % | 0.2 |
Water Absorption @24 hrs Saturation |
ISO 62:1999 | Immersion @ 23°C | % | 6.1 | % | 6.1 |
PROPERTY | TEST METHOD | NOTES | METRIC | UNITS | IMPERIAL | UNITS |
Tensile Strength at Yield | ISO 527-1/2:1993 | Sample Type 1B, 50mm/min | MPa | 74-78 | psi | 11.5k |
E-modulus | ISO 527-1/2:1993 | Sample Type 1B, 50mm/min | MPA | 3500-3700 | psi | 580k |
Elongation at Break | ISO 527-1/2:1993 | Sample Type 1B, 50mm/min | % | <30 | % | <30 |
Compressive Strength | ISO 604:2002 | Sample Type B, 5mm/min | MPa | 110-120 | psi | 14.7k |
Compressive Modulus | ISO 604:2002 | Sample Type A, 1mm/min | MPa | 2100-2500 | psi | 392k |
Flexural Strength | ISO 178:2001 | 1.5mm/min | MPa | 105-125 | psi | 15.3k |
Flexural Modulus | ISO 178:2001 | 1.5mm/min | MPa | 3300-3600 | psi | 478k |
Izod Impact Strength | ISO 180:2000 | Sample Type A (notched) | kJ/mm² | 5.0-6.5 | ft.lb/inE2 | 2.9 |
Dynamic Coefficient of Friction | 31.4m/min, 1.75MPa | 0.089 | 0.089 | |||
Limiting PV | MPa/m | 100 | psi.ft/min | 2.9k | ||
K-Factor (wear factor) | 31.4m/min, 1.75MPa | mm³/Nm | 2.2x10E-5 | 1.0x10E4 | ||
Hardness (Shore D ) | ISO 868: 2003 | Scale D | Shore D | 82 | Shore D | 82 |
PROPERTY | TEST METHOD | NOTES | METRIC | UNITS | IMPERIAL | UNITS |
Melting Temperature, Tg | °C | 222 | °F | 432 | ||
Glass Transition Temperature | ISO 11359:1999 | °C | 65 | °F | 149 | |
Heat Deflection Temperature, HDT/A | ISO 75 | 1.80MPa | °C | 75 | °F | 167 |
Maximum/Minimum Continuous Service Temperatures | °C | 110/-40 | °F | 230/-40 | ||
Maximum/Minimum Intermittent Service Temperatures | °C | 170/-100 | °F | 338/-148 | ||
Coefficient of Linear Thermal Expansion | ISO 11359-2:1999 | 23-55°C | °C-¹ | 8x10E-5 | °F,E-1 | 4.4x10E-5 |
Thermal Conductivity | ISO 8301:1991 | Mean T = 20°C | W/moC | 0.25 | °F | 0.15 |
Flammability | IEC 60695-11-10:2003-08 | HB | HB |
